CLHS Industrial Oil Fired Hot Water Heater Boiler For Greenhouse
Product Description
| Product Name | High Efficiency Hot Water Boiler
|
| Fuel Type | Oil |
| Thermal Efficiency |
90%
|
| Operation Control |
PLC Programmable Control
|
| After-sales Service Provided |
Engineers Available To Service Machinery Overseas
|
Application
Widely used in hospitals, schools, textile mills, garment
factories, dry cleaner, restaurants, hotels, canteens, food
factory, beverage factory, bean products, meat products factory,
slaughterhouses, cannery, brewery, pharmaceutical factory,
packaging plant, building materials factory, paint factory, beauty
salons, bath center, sauna, steam room, baby swimming pool and
other places of the enterprises and institutions.
Hot Water Boiler Model
| Item/Unit/Model | CLHS 0.06- 85/65-Y(Q) | CLHS 0.08-85/65-Y(Q) | CLHS 0.12-85/65-Y(Q) | CLHS 0.175-85/65-Y(Q) | CLHS 0.24-85/65-Y(Q) | CLHS 0.35-85/65- Y(Q) | CLHS 0.48-85/65-Y(Q) | CLHS 0.7- 86/60- Y(Q) |
| Rated Heat Capacity | MW | 0.06 | 0.08 | 0.12 | 0.175 | 0.24 | 0.35 | 0.48 | 0.7 |
| Working Pressure | Mpa | Non-pressure |
| Output Water Temp | ℃ | 85 |
| Input Water Temp | ℃ | 65 |
| Thermal Efficiency | % | 90 |
| Water Volume | L | 140 | 186 | 250 | 310 | 420 | 660 | 660 | 1400 |
| Water Outlet | DN | 50 | 50 | 50 | 65 | 65 | 80 | 80 | 100 |
| Water Inlet | DN | 50 | 50 | 50 | 65 | 65 | 80 | 80 | 1400 |
| Drain Valve | DN | 50 | 50 | 50 | 65 | 65 | 80 | 80 | 100 |
| Electric Consumption | Kw/h | 0.3 | 0.3 | 0.4 | 0.65 | 0.8 | 1 | 1 | 3.3 |
| Chimney | mm | 159 | 159 | 219 | 219 | 219 | 219 | 219 | 300 |
| Dimensions | Length | mm | 640 | 750 | 750 | 800 | 910 | 1060 | 1075 | 1400 |
| Width | mm | 640 | 750 | 750 | 800 | 910 | 1060 | 1075 | 1400 |
| Height | mm | 1320 | 1330 | 1560 | 1650 | 1770 | 1940 | 1980 | 2600 |
| Base Dimensions | mm | 640×640 | 750×750 | 750×750 | 790×790 | 910×910 | 1060×1060 | 1160×1160 | 1400×1400 |
| Transport Weight | Kg | 291 | 335 | 363 | 433 | 569 | 830 | 910 | 1274 |
| Fuel Consumption | Diesel | Kg/h | 5.6 | 7.5 | 11.3 | 16.4 | 22.5 | 32.8 | 52.1 | 65.7 |
| Natural Gas | Nm³/h | 6.6 | 8.86 | 13.2 | 19.4 | 26.6 | 38.8 | 42.2 | 77.5 |
| City Gas | Nm³/h | 13.2 | 17.7 | 26.4 | 38.8 | 53.2 | 77.6 | 106.4 | 155 |
| Largest Transport Size | Length | mm | 710 | 795 | 805 | 860 | 975 | 1130 | 1135 | 1470 |
| Width | mm | 730 | 730 | 730 | 894 | 1010 | 1150 | 1155 | 1500 |
| Height | mm | 1325 | 1325 | 1562 | 1652 | 1771 | 2001 | 2021 | 2331 |
Why Choose LEWAY Boiler?
1. Powerful technical support, over 10years experiences in boiler
making and selling inland& abroad
2. 2years Warranty & full-life services with many considerate
policies
3. Fast response within 24hours, 10-60days delivery after deposit
4. Engineer installation service, fast spare parts services
5. Factory selling with bottom price, as well as completed export
service
FAQ
A1: LEWAY Boiler provides completed installation drawing and
manual, or send engineer abroad for installation guidance
Q2:How many years is the boiler’s life span
A2: The boiler is designed for 10years life span, but under good
maintenance, usually the boiler can use at least 16years, LEWAY
Boiler provide full life after-sales service to each sold boiler
Q3: How is the warranty term?
A3: If any problems caused for quality during the warranty period,
the Seller will repair or replace the broken parts for free, if the
problem caused from the client’s side, the Seller will help supply
the spare part at lowest cost.
