Fire Tube Industrial Oil Fired High Efficiency Hot Water Boiler
Product Description
| Product Name |
High Efficiency Hot Water Boiler
|
| Fuel Type | Oil |
| Thermal Efficiency |
90%
|
| Operation Control |
PLC Programmable Control
|
| After-sales Service Provided |
Engineers Available To Service Machinery Overseas
|
Why Choose LEWAY Boiler?
1. Powerful technical support, over 10years experiences in boiler
making and selling inland& abroad
2. 2 years Warranty & full-life services with many considerate
policies
3. Fast response within 24hours, 10-60days delivery after deposit
4. Engineer installation service, fast spare parts services
5. Factory selling with bottom price, as well as completed export
service
Hot Water Boiler Model
| Item/Unit/Model | CLHS 0.06- 85/65-Y(Q) | CLHS 0.08-85/65-Y(Q) | CLHS 0.12-85/65-Y(Q) | CLHS 0.175-85/65-Y(Q) | CLHS 0.24-85/65-Y(Q) | CLHS 0.35-85/65- Y(Q) | CLHS 0.48-85/65-Y(Q) | CLHS 0.7- 86/60- Y(Q) |
| Rated Heat Capacity | MW | 0.06 | 0.08 | 0.12 | 0.175 | 0.24 | 0.35 | 0.48 | 0.7 |
| Working Pressure | Mpa | Non-pressure |
| Output Water Temp | ℃ | 85 |
| Input Water Temp | ℃ | 65 |
| Thermal Efficiency | % | 90 |
| Water Volume | L | 140 | 186 | 250 | 310 | 420 | 660 | 660 | 1400 |
| Water Outlet | DN | 50 | 50 | 50 | 65 | 65 | 80 | 80 | 100 |
| Water Inlet | DN | 50 | 50 | 50 | 65 | 65 | 80 | 80 | 1400 |
| Drain Valve | DN | 50 | 50 | 50 | 65 | 65 | 80 | 80 | 100 |
| Electric Consumption | Kw/h | 0.3 | 0.3 | 0.4 | 0.65 | 0.8 | 1 | 1 | 3.3 |
| Chimney | mm | 159 | 159 | 219 | 219 | 219 | 219 | 219 | 300 |
| Dimensions | Length | mm | 640 | 750 | 750 | 800 | 910 | 1060 | 1075 | 1400 |
| Width | mm | 640 | 750 | 750 | 800 | 910 | 1060 | 1075 | 1400 |
| Height | mm | 1320 | 1330 | 1560 | 1650 | 1770 | 1940 | 1980 | 2600 |
| Base Dimensions | mm | 640×640 | 750×750 | 750×750 | 790×790 | 910×910 | 1060×1060 | 1160×1160 | 1400×1400 |
| Transport Weight | Kg | 291 | 335 | 363 | 433 | 569 | 830 | 910 | 1274 |
| Fuel Consumption | Diesel | Kg/h | 5.6 | 7.5 | 11.3 | 16.4 | 22.5 | 32.8 | 52.1 | 65.7 |
| Natural Gas | Nm³/h | 6.6 | 8.86 | 13.2 | 19.4 | 26.6 | 38.8 | 42.2 | 77.5 |
| City Gas | Nm³/h | 13.2 | 17.7 | 26.4 | 38.8 | 53.2 | 77.6 | 106.4 | 155 |
| Largest Transport Size | Length | mm | 710 | 795 | 805 | 860 | 975 | 1130 | 1135 | 1470 |
| Width | mm | 730 | 730 | 730 | 894 | 1010 | 1150 | 1155 | 1500 |
| Height | mm | 1325 | 1325 | 1562 | 1652 | 1771 | 2001 | 2021 | 2331 |
After-sales Service
1. Engineers available to service machinery overseas.
2. We can guarantee 3 years for the boiler host,and also warranty 2
years for auxiliary boiler.
3. If there is any problem in install and use process, fell free to
contact us and we will get back to you in first time to solve the
problem
4. If our reply is still no solution to boiler problems, we will
send engineers on-site service.
Packaging & Shipping
1. Packing way: nude packaging for boiler main part and wood box
packaging for boiler accessories.
2. All goods will be reforced after packing into containers.
3. We have stable shipping company to cooperate. They will confirm
the safty of the goods.
4. Shipping way is different according to customer's country.
Mostly by sea. Some country by train.
