Steam Out Fast Biomass Fired Boiler , Commercial Biomass Boiler Coal Fuel Type

Ask Lasest Price
Brand Name :	LEWAY BOILER
Model Number :	DZL
Certification :	SGS, ISO, OHSAS
Price :	Negotiable
Supply Ability :	3000 Ton/Tons per Year
Delivery Time :	Within 20 working days

Add to Cart

Product Details
Company Profile

Steam Out Fast Biomass Fired Boiler , Commercial Biomass Boiler Coal Fuel Type

Steam Out Fast 6T Biomass Steam Boiler Industrial Biomass Steam Boiler

Product Description

Product Name	Biomass Steam Boiler
Fuel Type	Biomass
Thermal Efficiency	80%
Operation Control	Automatic
Structure	Fire Tubes
After-sales Service Provided	Engineers Available To Service Machinery Overseas

Our Service

1. Consultation service: Experienced technicians guidance is available on the phone, and on the internet.

2. Installation service: One or more engineers will be dispatched to the installation site to help install the customers’ boilers.

3. Training service: We also provide necessary training about boiler operation and daily maintenance to local workers.

4. Warm service: Based on customers’ request and budget, our experts make efficient, reliable solutions, and we produce strictly following customers’ order. Every customer has the chance to visit our workshops before placing the order.

Steam Boiler Model

Item/Unit/Model			DZL1- 0.7(1.25)	DZL2-0.7(1.25)	DZL4- 1.25	DZL6- 1.25	DZL8- 1.25	DZL10-1.25
Rated steam capacity		t/h	1	2	4	6	8	10
Rated working pressure		Mpa	0.7(1.25)	0.7(1.25)	1.25	1.25	1.25	1.25
Rated steam temperature		℃	171(194)	171(194)	194	194	194	194
Rated feedwater temperature		℃	20	20	20	20	20	20
Heating surface		㎡	39.5	76.12	135.98	226.72	396.26	412.3
Grate area		㎡	2.65	3.74	4.3	7.22	10.3	11.8
Fuel type		kg	Coal	Coal	Coal	Coal	Coal	Coal
Thermal efficiency		%	77.16	77	78	81	81	79.6
Fuel consumption		kg/h	155	311	615	888	1185	1507
Emission concentration		mg/Nm³	＜80	＜80	＜80	＜80	＜80	＜80
External Dimension	L	m	4.12	5.6	6.78	6.92	7.56	9.5
	W	m	1.92	2.6	2.73	2.83	3.28	3.35
	H	m	3.25	3.32	3.25	3.72	4.25	4.9
Boiler Weight		t	11.5	22.73	27.26	38.13	54.26	57.63
Main steam valve		mm	50	80	100	150	150	150
Feedwater valve		mm	32	40	40	40	40	50
Safety valve		mm	2×40	2×50	2×50	2×80	2×80	2×80
Drain valve		mm	40	40,50	40,50	40,50	40,50	40,50
Level gauge		mm	25	25	25	25	25	25

Advantage

1. No need special protection when power off.

2. Higher efficiency,heating fast.

3. Safe and reliable.

4. Easy to install.

Application

Medicine, chemical, light industry, textile, building material, cultivation, food and beverage, plastic foam, printing, dyeing and washing, rubber processing, paper products,wood processing, hotel, clothing and leather manufacturer etc.
