Fire Tube Natural Gas Hot Water Boiler Big Volume Combustion Room Design

Ask Lasest Price
Brand Name :	LEWAY BOILER
Model Number :	CWNS
Certification :	SGS, ISO, OHSAS
Price :	Negotiable
Payment Terms :	L/C, T/T
Supply Ability :	300 Ton/Tons per Month hot water boiler
Delivery Time :	Average 15 Days

Add to Cart

Product Details
Company Profile

Fire Tube Natural Gas Hot Water Boiler Big Volume Combustion Room Design

Fire Tube Natural Gas Hot Water Boiler , Industrial Hot Water Boiler

Product Description

Product Name	Natural Gas Hot Water Boiler
Fuel Type	Natural Gas, LNG, LPG, CNG
Thermal Efficiency	95%
Operation Control	PLC Programmable Control
After-sales Service Provided	Engineers Available To Service Machinery Overseas

Features

1. Applied international latest technology for big volume combustion room design, and use Italy combustion machine.

2. Corrugated furnace design make large heat transfer area and protect furnace.

3. Using fire-tube with screw thread, 1-2 faster heat transfer efficiency and remove hidden danger of welding cracks.

4. Wet-back boiler reduce faults rate and maintenance cost.

5. With protection devices for overheating, overpressure, lacking water, leak detection, flameout etc.

Hot Water Boiler Model

Item / Unit / Model			CWNS 0.35- 85/65-Y(Q)	CWNS 0.48- 85/65-Y(Q)	CWNS 0.58-85/65-Y(Q)	CWNS 0.7- 85/65-Y(Q)	CWNS 1.05-85/65- Y(Q)	CWNS 1.4-85/65-Y(Q)	CWNS 2.1-85/65-Y(Q)	CWNS 2.8-85/65-Y(Q)	CWNS 4.2-85/65-Y(Q)	CWNS 5.6-85/65-Y(Q)	CWNS 7.0-85/65-Y(Q)
Rated Heat Capacity		MW	0.35	0.48	0.58	0.7	1.05	1.4	2.1	2.8	4.2	5.6	7.0
Working Pressure		MPa	Non Pressure
Inlet/Outlet Water Temperature		℃	85/65	85/65	85/65	85/65	85/65	85/65	85/65	85/65	85/65	85/65	85/65
Heating Surface		㎡	19.5	21	31	34.2	50.2	65.76	93.61	113.44	187.1	260.36	273.7
Thermal Efficiency		%	91-98%
Fuel Consumption	Natural Gas	Nm³/h	36/38	49/52	59/63	71/76.7	104/112	142/153.4	208/226.1	280/304.8	414/440.3	547/602.5	680/730
Fuel Consumption	Diesel	Kg/h	32.5	44.5	53.8	64.9	97.4	139.9	194.8	259.8	376.5	497.6	623.7
Electric Consumption		KW/h	1.1	2.3	2.3	2.3	4.0	4.7	7.5	8.2	11	15	22
Transport Weight		Kg	1550	1650	1950	2100	2900	3500	4950	5190	10600	16000	19104
Water Volume		L	700	850	1100	1500	1848	2700	3600	5000	9000	13300	13300
Dimension	Length	mm	2260	2280	2395	2695	3205	3685	3915	4415	5300	6420	6822
	Width	mm	1120	1120	1475	1475	1475	1665	1750	1900	2380	2528	2550
	Height	mm	1550	1590	1750	1750	1750	2015	2160	2300	2742	3015	3064
Water Outlet Pipe		mm	80	80	100	100	125	150	150	200	200	250	250
Water Inlet Pipe		mm	80	80	100	100	125	150	150	200	200	250	250
Atmosphere Open Pipe		mm	80	80	100	100	125	150	150	200	200	250	250
Drain Pipe		mm	40	40	40	40	40	40	40	40	40	40	40
Chimney		mm	250	250	250	250	250	300	350	400	600	700	800
Basement Dimensions	Length	mm	1950	1980	2050	2120	2620	3100	3100	3560	4100	5200	5380
Basement Dimensions	Width	mm	800	810	1000	1000	1000	1100	1200	1300	1750	2000	2100

Our Services

Pre-sale service:
Accept inquiry of customers ,confirmation of investment advice of choice of product ,assist the customers to design the workshop.

In-sale service:
Help customers finish the basal equipment ,technical training of customers’s workers ,practice of operation ,help to install ,train the operators in the workshop.

After-sale service:
24 hours service of technology inquiry, instant components supply, regularly technical service guidance of maintain,long distance malfunction control.

Unique service:
System up-grade,special design according to the customers’ requirement, mould renew, supply new technology and products information.

Packing & Delivery

According to customer's requirements, our company can provide FOB inland transporation, CFR/ CIF ocean delivery.
For ensure the customer get the quality products smoothly and safely, our company has professional transporation team for handling the cargo loading, safe transporation, cargo discharge.
