Features
1. All the electrical components have the CE and CCC certification
2. Cartridge Heaters can work for about 20000 hours
3. PLC full automatic intelligent control cabinet, operate
conveniently.
4. Full automatic interlock protection program, operate safely.
5. Reliable boiler auxiliaries, i.e. pressure controller, pressure
transmitter, water level alarm, safety valve, etc.
6. Large steam space, high steam quality.
7. Environmental protection.
8. Small occupation, save construction investment.
Steam Boiler Model
| Item /Unit/Model | WDR0.5-1.0-D | WDR-1.0-1.0-D | WDR1.5-1.0-D | WDR-2.0-1.0-D | WDR3.0-1.0-D | WDR4.0-1.0-D |
| Rated Heat Capacity | Kg/h | 500 | 1000 | 1500 | 2000 | 3000 | 4000 |
| Working Pressure | Mpa | 1 | 1 | 1 | 1 | 1 | 1 |
| Rated Steam Temp | ℃ | 184 | 184 | 184 | 184 | 184 | 184 |
| Feedwater Temp | ℃ | 20 |
| Thermal Efficiency | % | 98 |
| Water Volume | L | 2000 | 2600 | 2850 | 3415 | 5850 | 8100 |
| Steam Outlet | DN | 40 | 50 | 65 | 80 | 80 | 100 |
| Water Inlet | DN | 25 | 25 | 40 | 40 | 40 | 40 |
| Drain Valve | DN | 40 | 40 | 40 | 40 | 40 | 40 |
| Relief Valve | DN | 40 | 40 | 2×40 | 2×40 | 2×50 | 2×50 |
| Heating-Tube | Kw/h | 24 | 60 | 60 | 60 | 60 | 60 |
| Heating-Tube Unit | Qty | 15 | 12 | 18 | 24 | 36 | 47 |
| Dimensions | Length | mm | 2720 | 2970 | 3200 | 3700 | 4180 | 4790 |
| Width | mm | 1760 | 1860 | 1860 | 1800 | 2100 | 2180 |
| Height | mm | 1730 | 1830 | 1830 | 1830 | 1980 | 2100 |
| Base Dimensions | mm | 2220×900 | 2350×1000 | 2700×1000 | 3200×1000 | 3800×1100 | 4200×1200 |
| Transport Weight | Kg | 1650 | 2001 | 2228 | 2525 | 2930 | 3460 |
Our services
We have professional engineers service team. According to the
customers’ requirement and site specific condition, they can make
the suitable and optimal solution about the after-sales service.
Moreover, LEWAY Boiler set up sales and after sale facilitating
agencies around over 30 regions, to offer the high quality
services.
1. 24hours service hotline.
2. 24 months warranty after delivery.
3. Spare parts are equipped during shipment.
4. Provide instllation, commissioning and maintance service
anytime.
Packaging & Shipping
1. Packing way: nude packaging for boiler main part and wood box
packaging for boiler accessories.
2. Container packing: 20 container
3. All goods will be reforced after packing into containers.
4. We have stable shipping company to cooperate. They will confirm
the safty of the goods.
5. Shipping way is different according to customer's country.
Mostly by sea. Some country by train.
