Industrial Fire Tube Natural Gas Steam Boiler Two Fire Passes
Vertical
Product Description
| Product Name |
Natural Gas Steam Boiler
|
| Fuel Type |
Natural Gas,City Gas,Coal Gas
|
| Thermal Efficiency |
92%
|
| Operation Control |
PLC Programmable Control
|
| After-sales Service Provided |
Engineers Available To Service Machinery Overseas
|
Why choose our products?
We are a professional boilers factory.
1. Economically priced,exquisitely made. Experienced & responsible
QC that you can rely on;
2. Strict quality control system. From the material, welding, to
finished boiler shipment, from project , establishment, drawing
design, to final audit;
3. Scientific advanced rational and economical structure design;
4. Adequate supply capacity, punctual delivery time;
5. Each boiler system part is from first class brand all over the
world or China;
6. Best after-sale service is provided;
7. We are the stable and long term supplier of many top companies
in China.
Steam Boiler Model
| Item/Umit/Model | Steam Boiler |
| LHS0.3- | LHS0.5- | LHS0.75- | LHS1- |
| 0.7-Y.Q | 0.7-Y.Q | 1.0-Y.Q | 0.7-Y.Q | 0.7-Y.Q |
| Nominal Capacity | Kg/h | 300 | 500 | 500 | 750 | 1000 |
| Nominal Steam Pressure | Mpa | 0.7 | 0.7 | 1 | 0.7 | 0.7 |
| Nominal Steam Temperature | ℃ | 170 | 170 | 184 | 170 | 170 |
| Feed Water Temperature | ℃ | 20 |
| Thermal Efficiency | % | >90 |
| Water Volume | L | 660 | 770 | 770 | 1160 | 1310 |
| Steam Outlet | DN | 40 | 40 | 50 |
| Inlet | DN | 25 | 32 | 25 | 40 |
| Sewage Valve | DN | 40 |
| Safety Valve | DN | 40 | 40/40 |
| Smoke Crossing | mm | 219 | 300 |
| Base Dimensions | mm | 1190*1190 | 1450*1450 | 1620*1620 |
| Dimensions | Length | mm | 1450 | 1500 | 1750 |
| Width | mm | 1450 | 1500 | 1750 |
| Height | mm | 2250 | 2120 | 2250 | 2470 |
| Transport Weight | T | 1.4 | 1.78 | 2 | 2.3 | 2.46 |
| Gas Pressure | Kpa | 1.5-3.5 | 4-8 |
| Gas Pipe | DN | 32 | 40 | 50 |
| Fuel Consumption |
| L.N.G | Nm³/h | 23.5 | 39.2 | 58.8 | 78.4 |
| L.P.G | Nm³/h | 9 | 15 | 22.5 | 30 |
| C.G | Nm³/h | 50 | 83.3 | 124.9 | 166.6 |
Packaging & Shipping
1. Packing way: nude packaging for boiler main part and wood box
packaging for boiler accessories.
2. Container packing: 20 container
3. All goods will be reforced after packing into containers.
4. We have stable shipping company to cooperate. They will confirm
the safty of the goods.
5. Shipping way is different according to customer's country.
Mostly by sea. Some country by train.
After-sales Service
1. Engineers available to service machinery overseas.
2. We can guarantee 3 years for the boiler host,and also warranty 2
years for auxiliary boiler.
3. If there is any problem in install and use process, fell free to
contact us and we will get back to you in first time to solve the
problem
4. If our reply is still no solution to boiler problems, we will
send engineers on-site service.
